Race Face Cinch 1x Direct Mount Chainrings

Race Face Cinch 1x Direct Mount Chainrings

Narrow-wide direct mount chainrings for Race Face Cinch cranks. The chainring is designed to give the optimum chainline – in the middle of the cassette – providing the smoothest shifting across the cassette and a straighter chain when in the largest or smallest cog.

The tooth profile of our narrow-wide chainrings maintain excellent wear for a durable product.

Fits:

• NSB Talon Crankset
• RaceFace Cranksets
• Other cranksets that use the Cinch DM system

Compatible with all 9, 10, 11, & 12-speed SRAM drivetrains (not T-Type)
Compatible with all 9, 10, & 11-speed Shimano drivetrain

Specifications:

• Bottom Bracket Types: GXP, Boost and BB30
• Machined from solid 7075 T6 Aluminum
• Anodized black with laser-etched graphics

Chainline:

• BB30: 48mm from the bottom bracket centre
• GXP: 48mm from the bottom bracket centre
• Boost: 51mm from the bottom bracket centre

Ring Offsets:

• GXP: 6mm
• Boost: 3mm
• BB30: 0mm

Weight:

• 28T – 75g
• 30T – 85g
• 32T – 95g
• 34T – 105g
• 36T – 115g

Precision CNC Machined in Whistler, BC.
